Product Parameters
|
Model |
Single or double lifting speed based on client's request |
||||||||
|
0.5-01 |
01-01 |
01-02 |
1.5-01 |
02-01 |
02-02 |
2.5-01 |
03-01 |
03-02 |
|
|
Capacity(T) |
0.5 |
1 |
1 |
1.5 |
2 |
2 |
2.5 |
3 |
3 |
|
Lifting speed(m/min) |
7.2/2.4 |
6.9/2.3 |
3.6/1.2 |
8.8/2.9 |
6.6/2.2 |
3.3/1.1 |
5.6/1.8 |
5.6/1.8 |
3.3/1.1 |
|
Motor power(kw) |
1.1/0.37 |
1.8/0.6 |
1.1/0.37 |
3.0/1.0 |
3.0/1.0 |
1.8/1.6 |
3.0/1.0 |
3.0/1.0 |
3.0/1.0 |
|
Rotation speed(r/min) |
1440 |
||||||||
|
Insulation grade |
F |
||||||||
|
Traveling speed(m/min) |
Fixed hook type or slow 11m/min,fast 21m/min |
||||||||
|
power supply |
3-phase 380v 50hz/according to client's request |
||||||||
|
control voltage |
24v 36v 48v |
||||||||
|
No.of load chain |
1 |
1 |
2 |
1 |
1 |
2 |
1 |
1 |
2 |
|
Spec.of load chain |
Φ6.3 |
Φ7.1 |
Φ6.3 |
Φ10 |
Φ10 |
Φ7.1 |
Φ11.2 |
Φ11.2 |
Φ10 |
|
Net weight(kg) |
47 |
65 |
53 |
108 |
108 |
73 |
115 |
115 |
131 |
|
I-beam(mm) |
75-125 |
75-178 |
75-178 |
82-178 |
82-178 |
82-178 |
100-178 |
100-178 |
100-178 |
05
Mar
05
Mar
04
Mar
“We replaced two of our old chain blocks with 1-ton electric chain hoists from this supplier. The difference in efficiency was immediate. They're quiet, compact, and the remote control makes awkward lifts much easier. Install took less than an hour.”
“For my custom metalwork business, I needed something affordable yet dependable. I wasn't expecting such a solid unit for the price. The lifting speed is decent, and it hasn’t overheated, even during longer lifts.”
